SLJY65/80D seal for SLJY desulphurization pump

Product Description:Double component mechanical seals for SLJY series desulphurization pump of Shandong Shuanglun Co., Ltd. application.
Product Description









Sdms Seal Co., Ltd. is a complete mechanical seals manufacture of design, engineering and repair of industrial sealing systems and control fluid. We offer products and services to very difficult medias: corrosive, clogging and crystallizing fluids.We produce mechanical pump seals, wave spring seals, single spring seals, multiple spring seals,welded metal bellows seals, metal roller bellows seal for alumina processing pumps,weir minerals pump ,slurry pump applications. Our supply replacement seals for AES, Ansi,Anga,John Crane,Eagle Burgmann,Chesterton,Roplan,Flowserve,Sharpe,Andritz,Ekato, Grundfos,ITT,KSB,Lightnin,Sulzer,Warman,Flygt,Katrex,Pac seal,Us seal, Sterling,Vulcan and many others. We also do repair of mechanical seals of all brands quickly and guarantee.We have certificate of API Spec Q1, CE, ISO9001, which will add to our product reliability.For product dimensions and more Information, please contact us.

Model No.: SLJY6580D   Style: cartridge mechanical seals

Material
Sealing ring : hard metal/SiC
Other metal parts : 2Cr13/304/316L
Auxiliary seal : FPM/FKM/MVQ/NBR

Design features
Double component mechanical seals for SLJY series desulphurization pump of Shandong Shuanglun Co., Ltd. application. Double faces seals structure,Primary sealing ring is silicon carbide integrated, the sealing effect is more better than mounted sealing ring.Secondary sealing ring is mounted tungsten carbide ring, the material of high hardness, high thermal conductivity and high wear resistance ensure the seal stability and durability.

Recommended Applications Pumps and Rotating Equipment
Shandong Shuanglun Co., Ltd.
SSC pump, SLJY series desulphurization pump

Packaging Details:standard export carton/plywood box or according to the requirement.Delivery Detail:normally 15-30 days, according to the quantity.
We are the real manufacturers from China, we can provide the picture of each product with multiple perspectives.

Sdms Seal Co.,Ltd. es un distribuidor large experiencia de dise?o, fabricación y reparacion de sistemas de sellado industrial y control de fluidos. Fabrica y venta de  sello mecanico estandar, sellos cartucho doble, sellos mecanicos de fuelle, cierres mecanicos para fuelle metálico, sellos mecanicos para bombas centrigugas y asi como lodos pesados en el procesamiento de minerals y en la fabricacion de materials primas.
los bombeo de lodo en los procesos de las mineras industrias.
Las marcas de sellos que reponemos diariamente son John Crane,Eagle Burgmann, Chesterton,Roplan,Flowserve,Sharpe, Andritz, Ekato, Grundfos,ITT,KSB,Lightnin,Sulzer,Warman, Flygt,Katrex,Aflas,AES,Sterling,Vulcan entre otros.Tambien hacemos reparación de sellos mecánicos de todas las marcas con rapidez y garantía. Estamos en condiciones de cerfificar API Spec Q1,CE, ISO9001,lo que agregará confiabilidad a nuestro producto.Por dimensiones y mayor informatión,contáctenos.

Nuestros materiales
Comportamiento químico, temperatura, viscosidad y presión de vapor, etc factores para elegir sellos mecánicos.Los sellos mecánicos pueden ser fabricados con diversos materiales.
Cuerpo del sello : aceros inoxidables304,316,316L y 2205 etc.
Cara rotatoria: hastelloy, carburo de silicio ,grafito y ceramica etc.
Asiento estacionario: hastelloy, carburo de silicio,grafito y ceramica etc.
Elastómeros: vitón, aflax, buna, propileno y silicona etc.

Ventajas
Bajo costo,Dise?o simple ,Fácil de instalar ,Repuestos intercambiables ,Adaptable a la mayoría de bombas












view:1090    lable:ssc pump seal,shuanglun pump seal,SLJY65/80D, filter pump seals,mechanical seals china,filtration pumps seals, SLJY desulphurization pump seals,sello mecanico bomba centrifuga,sellos bombas centrifugas,mechanical pump seals,  Chemical industry  Oil and gas industry  Power plant  Pulp and paper industry  Circulating pump  Chemical process pump  Chemical pumps  Chemical standard pumps  Desulphurization pump  Filter pump  Pulp pump  Shandong Shuanglun Co., Ltd.
Application
Design features
Double component seal
Pusher
Multiple springs
Independent of direction of rotation
Admissible axial movement ±1
Parameters
Temperature:150 ℃
Pressure:0.8 Mpa
Rinse:External flushing circulation
Speed:1500 r/min
Shaft via:80 mm
Technical data
