1527-35 for acid pump seal

Product Description:Universal simple acid pump mechanical seal, simple structure, easy processing, use of effective, low prices.
Product Description







Sdms Seal Co., Ltd. is a complete factory of design, manufacture and repair of mechanical seals for industrial sealing systems and control fluid in China.We produce inch & metric sizes shaft seals, single spring seals, multi spring seals,wave spring seals,metal bellows,welded metal bellows seals, rubber bellow seals, for pumps, compressors, mixers, reactors, agitator and other equipment revolving. Our supply replacement seals for AES, John Crane,Eagle Burgmann,Chesterton,Roplan,Flowserve,Sharpe,Andritz,Ekato, Grundfos,ITT,KSB,Lightnin,Sulzer,Warman,Sterling,Vulcan and many others. We also do repair of mechanical seals of all brands quickly and guarantee.We have certificate of API Spec Q1, CE, ISO9001, which will add to our product reliability.For product dimensions and more Information, please contact us.

Model No.: 2100    Style: mechanical seals elastomer bellows

Material
Sealing ring : hard metal
Other metal parts : 2Cr13/304/316L
Auxiliary seal : FPM/FKM/MVQ/NBR

Design features
Universal simple acid pump mechanical seal, simple structure, easy processing, use of effective, low prices. The 1527 series of mechanical seals with shaft diameter 25-125mm, big quantity in stock. This kind of mechanical seal by a large spring force to provide compensation for the ring. Effective number of turns in the same case, the total number of turns of the spring more than the normal spring, the number of turns and are more tight ends in the spring, in order to ensure the spring and spring seat and ring connections more stable, steady play spring drive action. Big spring structure, component mechanical seal, the installation is more convenient. Conventionally, the spring is surrounded by the sealing medium, large springs in attempts to prevent corrosion are also an advantage.

Advantage
Low cost,Simple design,Easy to install,Interchangeable parts,Adaptable to most pumps

Recommended Applications Pumps and Rotating Equipment
General pumps factories
General pumps types

Packaging Details:standard export carton/plywood box or according to the requirement.Delivery Detail:normally 15-30 days, according to the quantity.
We are the real manufacturers from China, we can provide the picture of each product with multiple perspectives.

Sdms Seal Co.,Ltd. es  la empresa líder de dise?o, fabricación y reparacion de sello tipo cartucho y sello tipo components para sistemas de sellado industrial y control de fluidos en China.Fabricamos sellos de componentes, cierres mecánicos de resorte unico, cierres mecánicos de resortes multiples, cierres mecánicos de fuelle, sellos de ballesta, sellos de fuelles de metal para bombas, compresores, mezcladores, reactores,agitadores y otro equipo rotativo.Las marcas de sellos que reponemos diariamente son John Crane,Eagle Burgmann, Chesterton,Roplan,Flowserve,Sharpe, Andritz, Ekato, Grundfos,ITT,KSB,Lightnin,Sulzer,Warman, Flygt,Katrex,Aflas,AES,Sterling,Vulcan entre otros.Tambien hacemos reparación de sellos mecánicos de todas las marcas con rapidez y garantía. Estamos en condiciones de cerfificar API Spec Q1,CE, ISO9001,lo que agregará confiabilidad a nuestro producto.Por dimensiones y mayor informatión,contáctenos.

Nuestros materiales
Comportamiento químico, temperatura, viscosidad y presión de vapor, etc factores para elegir sellos mecánicos.Los sellos mecánicos pueden ser fabricados con diversos materiales.
Cuerpo del sello : aceros inoxidables304,316,316L y 2205 etc.
Cara rotatoria: hastelloy, carburo de silicio ,grafito y ceramica etc.
Asiento estacionario: hastelloy, carburo de silicio,grafito y ceramica etc.
Elastómeros: vitón, aflax, buna, propileno y silicona etc.

Ventajas
Bajo costo,Dise?o simple ,Fácil de instalar ,Repuestos intercambiables ,Adaptable a la mayoría de bombas


view:1410    lable:1527-35, acid pump seal,phosphoric acid pump seal,hydrochloric acid pump seal,acid pump mechanical seal, single spring seal,mechanical seal factory china, sello mecanico empresa,  Metallurgy  Fine chemical  Pulp and paper industry  Phosphoric acid pump  Acid pump  Hydrochloric acid pump  Feeding pump  Water / sewage water pumps  Acid proof pump  General type pumps
Application
Design features
Single component seal
Pusher
Single spring seals
Left direction of rotation
Right direction of rotation
Admissible axial movement ±3
Parameters
Temperature:150 ℃
Pressure:0.8 Mpa
Rinse:Without water
Speed:2200 r/min
Shaft via:35 mm
Technical data
