Reemplazar M37G series burgmann seals

Product Description:Universal simple mechanical seal,single seal component structure, usually in combination with other metal structure is mounted together.
Product Description




Sdms Seal Co., Ltd. is a manufacturer of design, engineering and repair of industrial sealing systems and control fluid.We produce inch & metric sizes shaft seals, single spring seals, multi spring seals,wave spring seals,metal bellows,welded metal bellows seals, rubber bellow seals application for pump industrial,marine,power generation,process industry. Our supply replacement seals for AES, Ansi,Anga,John Crane,Eagle Burgmann,Chesterton,Roplan,Flowserve,Sharpe,Andritz,Ekato, Grundfos,ITT,KSB,Lightnin,Sulzer,Warman,Flygt,Katrex,Pac seal,Us seal, Sterling,Vulcan and many others. We also do repair of mechanical seals of all brands quickly and guarantee.We have certificate of API Spec Q1, CE, ISO9001, which will add to our product reliability.For product dimensions and more Information, please contact us.


Model No.: M37G    Style: mechanical seals elastomer bellows mechanical seals component


Material
Sealing ring : hard metal/SiC
Other metal parts : 2Cr13/304/316/316L
Auxiliary seal : FPM/FKM/MVQ/NBR

Design features
Universal simple mechanical seal,single seal component structure, usually in combination with other metal structure is mounted together. Our company can according to the customer's actual needs to make specific design. The mechanical seal is a component structure, the installation process is easy to install because of operational difficulties affect the sealing effect, after the adoption of specific design, usually consists of a set cartridge mechanical seal, simplifying installation difficulty and reduce installation errors.

Advantage
Low cost,Simple design,Easy to install,Interchangeable parts,Adaptable to most pumps

Recommended Applications Pumps and Rotating Equipment
Burgmann M37G

Packaging Details:standard export carton/plywood box or according to the requirement.Delivery Detail:normally 15-30 days, according to the quantity.
We are the real manufacturers from China, we can provide the picture of each product with multiple perspectives.

Sdms Seal Co.,Ltd. es el fabricante líder de dise?o, fabricación y reparacion de sello cartucho para sistemas de sellado industrial y control de fluidos.Fabricamos cierres mecánicos de resorte unico, cierres mecánicos de resortes multiples, cierres mecánicos de fuelle, cierres para fuelle metálico, sellos de ballesta para bombas, mezcladores, reactores,agitadores y otro equipo rotativo en la industria quimica,maria,alimentacion y farmacia,petroleo y gas.Las marcas de sellos que reponemos diariamente son John Crane,Eagle Burgmann, Chesterton,Roplan,Flowserve,Sharpe, Andritz, Ekato, Grundfos,ITT,KSB,Lightnin,Sulzer,Warman, Flygt,Katrex,Aflas,AES,Sterling,Vulcan entre otros.Tambien hacemos reparación de sellos mecánicos de todas las marcas con rapidez y garantía. Estamos en condiciones de cerfificar API Spec Q1,CE, ISO9001,lo que agregará confiabilidad a nuestro producto.Por dimensiones y mayor informatión,contáctenos.

Nuestros materiales
Comportamiento químico, temperatura, viscosidad y presión de vapor, etc factores para elegir sellos mecánicos.Los sellos mecánicos pueden ser fabricados con diversos materiales.
Cuerpo del sello : aceros inoxidables304,316,316L y 2205 etc.
Cara rotatoria: hastelloy, carburo de silicio ,grafito y ceramica etc.
Asiento estacionario: hastelloy, carburo de silicio,grafito y ceramica etc.
Elastómeros: vitón, aflax, buna, propileno y silicona etc.

Ventajas
Bajo costo,Dise?o simple ,Fácil de instalar ,Repuestos intercambiables ,Adaptable a la mayoría de bombas

Replacement models, reemplazar modelos
More Models, Más Modelos

Mechanical seal Burgmann type M37G, Sello Burgmann tipo M37G,


view:1163    lable:m37g ,Reemplazar m37g sello,m37g cierre,Reemplazar burgmann sello,Reemplazar burgmann cierre,API seals manufacturer,sello cartucho fabricant,replace burgmann,replacement burgmann,  Fertilizer  Power plant  Pulp and paper industry  Chemical pumps  Coal filter press pump  Slurry pump,Mud pumps,Sludge pump  Burgmann
Application
Design features
Single component seal
Pusher
Left direction of rotation
Right direction of rotation
Admissible axial movement ±2
Parameters
Temperature:150 ℃
Pressure:0.8 Mpa
Rinse:Without water
Shaft via:20-80 mm
Technical data
